RHNUSERSERVERPREFS

DDL script

Columns

Name	Type	Nullable	Default value
USER_ID	NUMBER(38)	N
SERVER_ID	NUMBER(38)	N
NAME	VARCHAR2(64)	N
VALUE	VARCHAR2(1)	N
CREATED	TIMESTAMP(6) WITH LOCAL TIME ZONE	N	(current_timestamp)
MODIFIED	TIMESTAMP(6) WITH LOCAL TIME ZONE	N	(current_timestamp)

Foreign Keys:

Constraint Name	Columns	Referenced table	Referenced Constraint	On Delete Rule
RHN_USERSERVERPREFS_SID_FK	SERVER_ID	RHNSERVER	RHN_SERVER_ID_PK	NO ACTION
RHN_USERSERVERPREFS_UID_FK	USER_ID	WEB_CONTACT	WEB_CONTACT_PK	CASCADE

Options:

Option	Settings
Tablespace	USERS
Index Organized	No
Generated by Oracle	No
Clustered	No
Nested	No
Temporary	No

Indexes:

Index Name	Type	Unuqueness	Columns	DDL script
RHN_USPREFS_SID_IDX	NORMAL	NONUNIQUE	SERVER_ID	DDL script
RHN_USPREFS_UID_SID_N_UQ	NORMAL	UNIQUE	USER_ID , SERVER_ID , NAME	DDL script

Triggers

RHN_U_S_PREFS_MOD_TRIG

Legend: comment string keyword reserved word operator

CREATE TRIGGER
rhn_u_s_prefs_mod_trig
before insert or update on rhnUserServerPrefs
for each row

REFERENCING NEW AS NEW OLD AS OLD
begin
        :new.modified := current_timestamp;
        :new.value := upper(:new.value);
end;
