RHNSYSTEMMIGRATIONS

Columns

Name	Type	Nullable	Default value	Comment
ORG_ID_TO	NUMBER(38)	Y
ORG_ID_FROM	NUMBER(38)	Y
SERVER_ID	NUMBER(38)	N
MIGRATED	TIMESTAMP(6) WITH LOCAL TIME ZONE	N	(current_timestamp)

Foreign Keys:

Constraint Name	Columns	Referenced table	Referenced Constraint	On Delete Rule
RHN_SYS_MIG_OIDFRM_FK	ORG_ID_FROM	WEB_CUSTOMER	WEB_CUSTOMER_ID_PK	SET NULL
RHN_SYS_MIG_OIDTO_FK	ORG_ID_TO	WEB_CUSTOMER	WEB_CUSTOMER_ID_PK	SET NULL
RHN_SYS_MIG_SID_FK	SERVER_ID	RHNSERVER	RHN_SERVER_ID_PK	CASCADE

Options:

Option	Settings
Tablespace	USERS
Index Organized	No
Generated by Oracle	No
Clustered	No
Nested	No
Temporary	No

Indexes:

Index Name	Type	Unuqueness	Columns	DDL script
RSM_ORG_ID_FROM_IDX	NORMAL	NONUNIQUE	ORG_ID_FROM	DDL script
RSM_ORG_ID_TO_IDX	NORMAL	NONUNIQUE	ORG_ID_TO	DDL script
