Spacewalk DB Schema - Table-RHNSNAPSHOTCHANNEL

Main Tables Views Materialized Views Indexes Constraints Triggers Procedures Functions Packages Sequences Java Sources Jobs Sanity Check Index DDL scrips

Description Columns Primary key Check Constraints Foreign keys Unique Keys Options Indexes Referenced by Triggers Partitions

RHNSNAPSHOTCHANNEL

DDL script

Columns

Name	Type	Nullable	Default value	Comment
SNAPSHOT_ID	NUMBER(38)	N
CHANNEL_ID	NUMBER(38)	N

Foreign Keys:

Constraint Name	Columns	Referenced table	Referenced Constraint	On Delete Rule
RHN_SNAPCHAN_CID_FK	CHANNEL_ID	RHNCHANNEL	RHN_CHANNEL_ID_PK	NO ACTION
RHN_SNAPCHAN_SID_FK	SNAPSHOT_ID	RHNSNAPSHOT	RHN_SNAPSHOT_ID_PK	CASCADE

Options:

Option	Settings
Tablespace	USERS
Index Organized	No
Generated by Oracle	No
Clustered	No
Nested	No
Temporary	No

Indexes:

Index Name	Type	Unuqueness	Columns	DDL script
RHN_SNAPCHAN_SID_CID_UQ	NORMAL	UNIQUE	SNAPSHOT_ID , CHANNEL_ID	DDL script
RHN_SNAPSHOT_CID_IDX	NORMAL	NONUNIQUE	CHANNEL_ID	DDL script

Triggers

RHN_SNAPCHAN_MOD_TRIG

Legend: comment string keyword reserved word operator

CREATE TRIGGER
rhn_snapchan_mod_trig
before insert or update on rhnSnapshotChannel
for each row

REFERENCING NEW AS NEW OLD AS OLD
begin
	update rhnSnapshot set modified = current_timestamp where id = :new.snapshot_id;
end;
