RHNSERVERNOTES

DDL script

Columns

Name	Type	Nullable	Default value
ID	NUMBER(38)	N
CREATOR	NUMBER(38)	Y
SERVER_ID	NUMBER(38)	N
SUBJECT	VARCHAR2(80)	N
NOTE	VARCHAR2(4000)	Y
CREATED	TIMESTAMP(6) WITH LOCAL TIME ZONE	N	(current_timestamp)
MODIFIED	TIMESTAMP(6) WITH LOCAL TIME ZONE	N	(current_timestamp)

Primary key:

Constraint Name	Columns
RHN_SERVERNOTES_ID_PK	ID

Foreign Keys:

Constraint Name	Columns	Referenced table	Referenced Constraint	On Delete Rule
RHN_SERVERNOTES_CREATOR_FK	CREATOR	WEB_CONTACT	WEB_CONTACT_PK	SET NULL
RHN_SERVERNOTES_SID_FK	SERVER_ID	RHNSERVER	RHN_SERVER_ID_PK	NO ACTION

Options:

Option	Settings
Tablespace	USERS
Index Organized	No
Generated by Oracle	No
Clustered	No
Nested	No
Temporary	No

Indexes:

Index Name	Type	Unuqueness	Columns	DDL script
RHN_SERVERNOTES_CREATOR_IDX	NORMAL	NONUNIQUE	CREATOR	DDL script
RHN_SERVERNOTES_ID_PK	NORMAL	UNIQUE	ID	DDL script
RHN_SERVERNOTES_SID_IDX	NORMAL	NONUNIQUE	SERVER_ID	DDL script

Triggers

RHN_SERVERNOTES_MOD_TRIG

Legend: comment string keyword reserved word operator

CREATE TRIGGER
rhn_servernotes_mod_trig
before insert or update on rhnServerNotes
for each row

REFERENCING NEW AS NEW OLD AS OLD
begin
        :new.modified := current_timestamp;
end;
