RHNSERVERGROUPMEMBERS

DDL script

Columns

Name	Type	Nullable	Default value
SERVER_ID	NUMBER(38)	N
SERVER_GROUP_ID	NUMBER(38)	N
CREATED	TIMESTAMP(6) WITH LOCAL TIME ZONE	N	(current_timestamp)
MODIFIED	TIMESTAMP(6) WITH LOCAL TIME ZONE	N	(current_timestamp)

Foreign Keys:

Constraint Name	Columns	Referenced table	Referenced Constraint	On Delete Rule
RHN_SG_GROUPS_FK	SERVER_GROUP_ID	RHNSERVERGROUP	RHN_SERVERGROUP_ID_PK	NO ACTION
RHN_SG_MEMBERS_FK	SERVER_ID	RHNSERVER	RHN_SERVER_ID_PK	NO ACTION

Options:

Option	Settings
Tablespace	USERS
Index Organized	No
Generated by Oracle	No
Clustered	No
Nested	No
Temporary	No

Indexes:

Index Name	Type	Unuqueness	Columns	DDL script
RHN_SGMEMBERS_SGID_IDX	NORMAL	NONUNIQUE	SERVER_GROUP_ID	DDL script
RHN_SGMEMBERS_SID_SGID_UQ	NORMAL	UNIQUE	SERVER_ID , SERVER_GROUP_ID	DDL script

Triggers

RHN_SERVER_GROUP_ORG_MAPPING

Legend: comment string keyword reserved word operator

CREATE TRIGGER
rhn_server_group_org_mapping
BEFORE INSERT OR UPDATE ON rhnServerGroupMembers
FOR EACH ROW

REFERENCING NEW AS NEW OLD AS OLD
DECLARE
        same_org        NUMBER;
BEGIN
        same_org := 0;
        SELECT 1 INTO same_org
          FROM rhnServer S, rhnServerGroup SG
         WHERE SG.org_id = S.org_id
           AND S.id = :new.server_id
           AND SG.id = :new.server_group_id;
        IF same_org = 0 THEN
          rhn_exception.raise_exception('sgm_insert_diff_orgs');
        END IF;
EXCEPTION
        WHEN NO_DATA_FOUND THEN
          rhn_exception.raise_exception('sgm_insert_diff_orgs');
END;

RHN_SG_MEMBER_MOD_TRIG

Legend: comment string keyword reserved word operator

CREATE TRIGGER
rhn_sg_member_mod_trig
before insert or update on rhnServerGroupMembers
for each row

REFERENCING NEW AS NEW OLD AS OLD
begin
        :new.modified := current_timestamp;
end;
