RHNARCHTYPEACTIONS

DDL script

Columns

Name	Type	Nullable	Default value
ARCH_TYPE_ID	NUMBER(38)	N
ACTION_STYLE	VARCHAR2(64)	N
ACTION_TYPE_ID	NUMBER(38)	N
CREATED	TIMESTAMP(6) WITH LOCAL TIME ZONE	N	(current_timestamp)
MODIFIED	TIMESTAMP(6) WITH LOCAL TIME ZONE	N	(current_timestamp)

Foreign Keys:

Constraint Name	Columns	Referenced table	Referenced Constraint	On Delete Rule
RHN_ARCHTYPEACTS_ACTID_FK	ACTION_TYPE_ID	RHNACTIONTYPE	RHN_ACTION_TYPE_PK	NO ACTION
RHN_ARCHTYPEACTS_ATID_FK	ARCH_TYPE_ID	RHNARCHTYPE	RHN_ARCHTYPE_ID_PK	NO ACTION

Options:

Option	Settings
Tablespace	USERS
Index Organized	No
Generated by Oracle	No
Clustered	No
Nested	No
Temporary	No

Indexes:

Index Name	Type	Unuqueness	Columns	DDL script
RHN_ARCHTYPEACTS_ATID_AS_UQ	NORMAL	UNIQUE	ARCH_TYPE_ID , ACTION_STYLE	DDL script

Triggers

RHN_ARCHTYPEACTS_MOD_TRIG

Legend: comment string keyword reserved word operator

CREATE TRIGGER
rhn_archtypeacts_mod_trig
before insert or update on rhnArchTypeActions
for each row

REFERENCING NEW AS NEW OLD AS OLD
begin
	:new.modified := current_timestamp;
end;
