RHNACTIONCHAINENTRY

DDL script

Columns

Name	Type	Nullable	Default value
ACTIONCHAIN_ID	NUMBER(38)	N
ACTION_ID	NUMBER(38)	Y
SERVER_ID	NUMBER(38)	N
SORT_ORDER	NUMBER(38)	N
CREATED	DATE	N	(SYSDATE)
MODIFIED	DATE	N	(SYSDATE)

Foreign Keys:

Constraint Name	Columns	Referenced table	Referenced Constraint	On Delete Rule
RHN_ACTCHAINENT_ACID_FK	ACTIONCHAIN_ID	RHNACTIONCHAIN	RHN_ACTION_CHAIN_ID_PK	CASCADE
RHN_ACTCHAINENT_AID_FK	ACTION_ID	RHNACTION	RHN_ACTION_PK	CASCADE
RHN_ACTCHAINENT_SID_FK	SERVER_ID	RHNSERVER	RHN_SERVER_ID_PK	CASCADE

Options:

Option	Settings
Tablespace	USERS
Index Organized	No
Generated by Oracle	No
Clustered	No
Nested	No
Temporary	No

Indexes:

Index Name	Type	Unuqueness	Columns	DDL script
RHN_ACTCHAINENT_AID_UQ	NORMAL	UNIQUE	ACTION_ID	DDL script

Triggers

RHN_ACTCHAINENT_MOD_TRIG

Legend: comment string keyword reserved word operator

CREATE TRIGGER
rhn_actchainent_mod_trig
    BEFORE INSERT OR UPDATE ON rhnActionChainEntry
    FOR EACH ROW

REFERENCING NEW AS NEW OLD AS OLD
BEGIN
        :new.modified := sysdate;
    END;
